POLYESTER FLOOR STANDING CABINETS

– Completely sealed enclosure (PLA version).

– Enclosure with ventilated canopy (PLAT version).

– Enclosure with plinth-type open bottom (PLAZ version).

– Enclosure with plinth-type open bottom and ventilated canopy (PLAZT version).

– Note: The first letters of the references relate to the version.

– 5 heights from 500 to 1500 mm.

– 4 widths: 500 and 750 (1 door), 1000 and 1250 mm (2 doors).

– 2 depths: 320 and 420 mm.

– Note: The figures included in the references of the enclosures and products of the range represent the dimension in mm of the product in question.

– The 2-door enclosures comprise a central upright, which can be removed in certain conditions. Please contact us.

– Plain door.

– Door with transparent window (index T at the end of the reference).

– Door with anti-posting surface (index R at the end of the reference).

Impact resistance IK 10 for the plain doors and all sides and IK 08 for the glazed door.

2-point closure for heights of 500 and 750 mm and 4-point closure points for heights > 1000 mm.

Characteristics of the material

The floor-standing enclosures are made from polyester reinforced with fibreglass, moulded by hot compression, RAL 7035 grey. This material:

Is insulating: several kV per mm.
Can be machined easily.
Is resistant to corrosion: does not rust and can withstand many chemical substances.

Is self-extinguishing (does not propagate fire: HB40 classification and self-extinguishing in several seconds during the glow-wire test at 960 °C during 30s).

Polyester Floor standing cabinets

Sizes Available

External dimensions (mm)				References of enclosures with door		Metallic mounting plate
Height	Width	Depth	No of doors	Plain IP65	Glazed IP65
500	500	320	1	EPLA553	EPLA553T	EPMM55
		420	1	EPLA554	EPLA554T
	750	320	1	EPLA573	EPLA573T	EPMM75
		420	1	EPLA574	EPLA574T
	1000	320	2	EPLA5103	EPLA5103T	EPMM510
		420	2	EPLA5104	EPLA5104T
	1250	320	2	EPLA5123	EPLA5123T	EPMM55 + EPMM75
		420	2	EPLA5124	EPLA5124T
750	500	320	1	EPLA753	EPLA753T	EPMM75
		420	1	EPLA754	EPLA754
	750	320	1	EPLA773	EPLA773T	EPMM77
		420	1	EPLA774	EPLA774T
	1000	320	2	EPLA7103	EPLA7103T	EPMM710
		420	2	EPLA7104	EPLA7104T
	1250	320	2	EPLA7123	EPLA7123T	EPMM712
		420	2	EPLA7124	EPLA7124T
1000	500	320	1	EPLA1053	EPLA1053T	EPMM105
		420	1	EPLA1054	EPLA1054T
	750	320	1	EPLA1073	EPLA1073T	EPMM107
		420	1	EPLA1074	EPLA1074T
	1000	320	2	EPLA10103	EPLA10103T	EPMM1010
		420	2	EPLA10104	EPLA10104T
	1250	320	2	EPLA10123	EPLA10123T	EPMM1012
		420	2	EPLA10124	EPLA10124T
1250	500	320	1	EPLA1253	EPLA1253T	EPMM125
		420	1	EPLA1254	EPLA1254T
	750	320	1	EPLA1273	EPLA1273T	EPMM127
		420	1	EPLA1274	EPLA1274T
	1000	320	2	EPLA12103	EPLA12103T	EPMM1210
		420	2	EPLA12104	EPLA12104T
	1250	320	2	EPLA12123	EPLA12123T	EPMM1212
		420	2	EPLA12124	EPLA12124T
1500	500	320	1	EPLA1553	EPLA1553T	EPMM155
		420	1	EPLA1554	EPLA1554T
	750	320	1	EPLA1573	EPLA1573T	EPMM157
		420	1	EPLA1574	EPLA1574T
	1000	320	2	EPLA15103	EPLA15103T	EPMM1510
		420	2	EPLA15104	EPLA15104T
	1250	320	2	EPLA15123	EPLA15123T	EPMM1512
		420	2	EPLA15124	EPLA15124T
